Teknik Özellikler
- Renk
- Black
- Kurşunsuz
- Lead Free
- Pozisyon Sayısı
- 50
- Contact Finish Thickness
- 8.00μin 0.203μm
- Akım Değeri
- 3A
- Montaj
- Through Hole
- Dielectric Material
- Polybutylene Terephthalate (PBT)
- Connector Style
- D-Sub
- Terminal
- Solder
- Yayın Yılı
- 2012
- Ambalaj
- Tray
- Nominal Gerilim
- 350V
- Contact Finish
- Gold
- Pcb Contact Row Spacing
- 2.8448 mm
- Contact Materials
- Phosphor Bronze
- Shell Size Connector Layout
- 5 DD D
- Flange Feature
- Housing/Shell (Unthreaded)
- Length Termination
- 0.157 inch
- Housing Material
- PBT
- Terminal Adımı
- 2.7686mm
- Contact Resistance
- 15mOhm
- Seri
- SD
- Pcb Contact Pattern
- STAGGERED
- Contact Type
- Signal
- REACH Uyumluluk Kodu
- unknown
- Reference Standard
- UL
- RoHS Durumu
- RoHS Compliant
- Shell Material Finish
- Steel, Nickel Plated
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 8 Weeks
- Connector Type
- Receptacle, Female Sockets
- Sıra Sayısı
- 3
- Total Number Of Contacts
- 50
- Number Of Pcb Rows
- 3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reliability
- COMMERCIAL
- Montaj Tipi
- Panel Mount, Through Hole
- Rated Current Signal
- 3A
