RP13A-12PH-20SC(71)

Teknik Özellikler

Ambalaj

Bulk

Shell Material

Polycarbonate (PC)

Insulation Resistance

1000000000Ohm

Montaj Tipi

Free Hanging (In-Line)

Contact Resistance

30mOhm

Material Flammability Rating

UL94 V-0

Shell Size Insert

12

Çalışma Sıcaklığı

-10°C~60°C

Yayın Yılı

2004

REACH Uyumluluk Kodu

unknown

Tip

For Female Sockets

Parça Durumu

Active

Fabrika Tedarik Süresi

10 Weeks

Note

Contacts Not Included

Housing Color

Black

Contact Sizes

1.2mm

Connector Type

Plug Housing

Pozisyon Sayısı

20

Seri

RP13A

Kurşunsuz Kodu

yes

Insert Material

Polycarbonate (PC)

Contact Shape

Circular

Reliability

COMMERCIAL

Contact Type

Crimp

Dielectric Withstanding Voltage

300VAC V

Akım Değeri

2A

Orientation

Keyed

Number Of Ports

1

Fastening Type

Push-Pull

Nem Hassasiyeti (MSL)

1 (Unlimited)

Includes

6 pcs - 1 Connector, 1 Backshell, 1 Cable Clamp, 1 Screw, 1 Spring, 1 Strain Relief

Contact Plating

Silver

Contact Gender

Female

Rated Current Signal

2A

RoHS Durumu

RoHS Compliant

Nominal Gerilim

30V

Din Conformance

YES

Kurşunsuz

Lead Free

Contact Materials

Bronze

Wirecable Gauge

30 AWG
