RP13A-12PA-13SC(71)

Teknik Özellikler

Nominal Gerilim

100V

Ambalaj

Bulk

Insulation Materials

Plastic

Akım Değeri

2A

Contact Materials

Bronze

Contact Gender

Female

Seri

RP13A

Note

Contacts Not Included

Fabrika Tedarik Süresi

10 Weeks

Contact Shape

Circular

Uzunluk

47.2mm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Özellikler

Backshell, Cable Clamp, Strain Relief

Yayın Yılı

2009

Radyasyon Dayanımı

No

Pozisyon Sayısı

13

RoHS Durumu

RoHS Compliant

Housing Color

Black

Kurşunsuz

Lead Free

ECCN Kodu

EAR99

Contact Type

Crimp

Includes

6 pcs - 1 Connector, 1 Backshell, 1 Cable Clamp, 1 Screw, 1 Spring, 1 Strain Relief

Parça Durumu

Active

Orientation

Keyed

Shell Material

Polycarbonate (PC)

Wirecable Gauge

24 AWG

Connector Type

Plug Housing

Montaj Tipi

Free Hanging (In-Line)

Insert Material

Polycarbonate (PC)

Max Current Rating

2A

Contact Plating

Silver

Gender

Male

Fastening Type

Push-Pull

Shielding

Unshielded

HTS Kodu

8536.69.40.20

Contact Sizes

1.2mm 11 1.6mm 2

Montaj

Cable, Free Hanging

Çalışma Sıcaklığı

-10°C~60°C

Shell Size Insert

12

Material Flammability Rating

UL94 V-0
