Teknik Özellikler
- Contact Finish Thickness
- 8.00μin 0.203μm
- Pozisyon Sayısı
- 15
- Contact Materials
- Phosphor Bronze
- Sıra Sayısı
- 2
- Material Flammability Rating
- UL94 V-0
- Pcb Contact Pattern
- STAGGERED
- ECCN Kodu
- EAR99
- Renk
- Black
- Contact Type
- Signal
- Özellikler
- Board Lock
- Housing Material
- PBT
- Insulation Resistance
- 5000000000Ohm
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Tray
- Nominal Gerilim
- 350V
- HTS Kodu
- 8536.69.40.30
- Reference Standard
- UL
- Kurşunsuz
- Lead Free
- Body Depth
- 0.516 inch
- Akım Değeri
- 3A
- Fabrika Tedarik Süresi
- 10 Weeks
- Number Of Pcb Rows
- 2
- Seri
- RD*D
- Montaj
- Through Hole
- REACH Uyumluluk Kodu
- unknown
- Shell Material Finish
- Steel, Nickel Plated
- Body Breadth
- 0.494 inch
- Dielectric Material
- Polybutylene Terephthalate (PBT)
- Plating Thickness
- 8μin
- Connector Type
- Receptacle, Female Sockets
- Rated Current Signal
- 3A
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flange Feature
- Housing/Shell (M2.6)
- Dielectric Withstanding Voltage
- 1800VAC V
- Connector Style
- D-Sub
- Terminal
- Solder
- Total Number Of Contacts
- 15
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Body Length Or Diameter
- 1.541 inch
