RDAD-15P(55)

Teknik Özellikler

Contact Materials

Phosphor Bronze

Pozisyon Sayısı

15

Contact Finish Thickness

8.00μin 0.203μm

Sıra Sayısı

2

ECCN Kodu

EAR99

Pcb Contact Pattern

STAGGERED

Material Flammability Rating

UL94 V-0

Renk

Black

Contact Type

Signal

Insulation Resistance

5000000000Ohm

Housing Material

PBT

RoHS Durumu

RoHS Compliant

Ambalaj

Tray

Reference Standard

UL

HTS Kodu

8536.69.40.30

Nominal Gerilim

350V

Akım Değeri

3A

Fabrika Tedarik Süresi

8 Weeks

Number Of Pcb Rows

2

Seri

RD*D

Montaj

Through Hole

Yayın Yılı

2003

REACH Uyumluluk Kodu

unknown

Shell Material Finish

Steel, Nickel Plated

Dielectric Material

Polybutylene Terephthalate (PBT)

Connector Type

Plug, Male Pins

Parça Durumu

Active

Flange Feature

Housing/Shell (M2.6)

Nem Hassasiyeti (MSL)

1 (Unlimited)

Dielectric Withstanding Voltage

1750VAC V

Terminal

Solder

Connector Style

D-Sub

Total Number Of Contacts

15

Montaj Tipi

Panel Mount, Through Hole, Right Angle

Shell Size Connector Layout

2 DA A

Contact Finish

Gold

Çalışma Sıcaklığı

-55°C~85°C

Reliability

COMMERCIAL
