QR/P-4S-C(01)

Teknik Özellikler

Iec Conformance

NO

Contact Materials

NOT SPECIFIED

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Yayın Yılı

2005

Connector Style

Rack and Panel

Number Of Conductors

ONE

Total Number Of Contacts

4

Nem Hassasiyeti (MSL)

1 (Unlimited)

Mixed Contacts

NO

Montaj Tipi

Panel Mount

Seri

QR/P

RoHS Durumu

Non-RoHS Compliant

Option

GENERAL PURPOSE

Connector Type

Housing for Female Sockets

Reference Standard

UL,CSA,TUV

ECCN Kodu

EAR99

Empty Shell

YES

Filter Feature

NO

Parça Durumu

Obsolete

REACH Uyumluluk Kodu

unknown

Contact Finish Mating

NOT SPECIFIED

Insulation Resistance

5000000000Ohm

Kurşunsuz

Contains Lead

Mil Conformance

NO

Sıra Sayısı

2

Pozisyon Sayısı

4

Operating Temperature Max

60°C

Özellikler

Mating Guide

Insulation Materials

POLYBUTYLENE TEREPHTHALATE

Renk

Blue

Reliability

COMMERCIAL

Ambalaj

Bulk

Connector Usage

Receptacle

Operating Temperature Min

-10°C

Din Conformance

NO

Note

Contacts Not Included

Termination Type

CRIMP

Shell Material

POLYBUTYLENE TEREPHTHALATE

Pitch

0.177 4.50mm

Contact Resistance

10mOhm
