Adet bazlı fiyat
- 1+ adet$6.36
- 10+ adet$6.00
- 100+ adet$5.66
- 500+ adet$5.34
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Type
- Female Socket
- Total Number Of Contacts
- 9
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Polarization Key
- POLARIZED HOUSING
- Fabrika Tedarik Süresi
- 10 Weeks
- Sıra Sayısı
- 3
- Row Spacing
- 0.244 (6.20mm)
- Pozisyon Sayısı
- 9
- Body Breadth
- 0.528 inch
- Parça Durumu
- Active
- Montaj Tipi
- Free Hanging (In-Line)
- Contact Resistance
- 100mOhm
- Seri
- PS2
- Renk
- Black
- Operating Temperature Min
- -40°C
- Operating Temperature Max
- 105°C
- Durability
- 50 Cycles
- Contact Termination
- Crimp
- RoHS Durumu
- RoHS Compliant
- Dielectric Withstanding Voltage
- 1000VAC V
- Rated Current Signal
- 5A
- Insulation Materials
- SYNTHETIC RESIN
- Insulation Resistance
- 5000000000Ohm
- Ambalaj
- Bulk
- Reference Standard
- UL
- Reliability
- COMMERCIAL
- Pitch
- 0.181 4.60mm
- REACH Uyumluluk Kodu
- unknown
- Note
- Contacts Not Included
- Fastening Type
- Latch Lock
- Connector Type
- Receptacle
- Montaj
- Free Hanging
