Adet bazlı fiyat
- 1+ adet$106.11
- 10+ adet$100.10
- 100+ adet$94.43
- 500+ adet$89.09
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Plating
- Silver
- Akım Değeri
- 300A
- Body Depth
- 2.776 inch
- Connector Type
- Receptacle, Combination
- Montaj
- Panel
- REACH Uyumluluk Kodu
- unknown
- Note
- Contacts Not Included
- Fastening Type
- Latch Holder
- Reference Standard
- UL
- Reliability
- COMMERCIAL
- Insulation Materials
- SYNTHETIC RESIN
- Insulation Resistance
- 5000000000Ohm
- Ambalaj
- Bulk
- Özellikler
- Mounting Flange
- Contact Arrangement
- S12P2
- Durability
- 50 Cycles
- Contact Termination
- Crimp
- RoHS Durumu
- RoHS Compliant
- Dielectric Withstanding Voltage
- 1000VAC V
- Rated Current Signal
- 5A
- Operating Temperature Min
- -40°C
- Operating Temperature Max
- 105°C
- Renk
- Black
- HTS Kodu
- 8536.69.40.30
- ECCN Kodu
- EAR99
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Body Breadth
- 2.815 inch
- Contact Resistance
- 40mOhm
- Montaj Tipi
- Panel Mount
- Seri
- PS2
- Number Of Conductors
- ONE
- Pozisyon Sayısı
- 8 (2 Power (Loaded) + 6)
- Fabrika Tedarik Süresi
- 10 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Total Number Of Contacts
- 14
- Yayın Yılı
- 2017
- Body Length Or Diameter
- 9.055 inch
- Contact Type
- Female Socket
- Mixed Contacts
- YES
