PCN13-44S-2.54DS

Teknik Özellikler

Contact Style

SQ PIN-SKT

Sıra Sayısı

2

Pozisyon Sayısı

44

Contact Finish

Gold

Number Of Pcb Rows

2

Plating Thickness

3.93μin

Polarization Key

POLARIZED HOUSING

Montaj

Through Hole

Terminal

Solder

Material Flammability Rating

UL94 V-0

Uzunluk

73.6mm

Montaj Tipi

Through Hole, Right Angle

Pitch

0.100 2.54mm

Reliability

COMMERCIAL

Genişlik

15.2mm

Reference Standard

UL

Akım Değeri

2A

Insulator Color

BEIGE

Number Of Conductors

ONE

Contact Pattern

RECTANGULAR

Body Depth

0.453 inch

Material Insulation

Polybutylene Terephthalate (PBT)

REACH Uyumluluk Kodu

unknown

Flammability Rating

UL94 V-0

Yükseklik

8.1mm

Rated Current Signal

2A

Number Of Positions Loaded

All

Housing Color

Grey

Total Number Of Contacts

44

Ambalaj

Tray

Contact Finish Thickness

3.94μin 0.10μm

Level Class

1

Housing Material

Plastic

Nem Hassasiyeti (MSL)

1 (Unlimited)

RoHS Durumu

Non-RoHS Compliant

Connector Type

Receptacle, Female Sockets

Seri

PCN13

Kurşunsuz

Contains Lead

Çalışma Sıcaklığı

-55°C~85°C

Parça Durumu

Obsolete
