Adet bazlı fiyat
- 1+ adet$22.59
- 10+ adet$21.31
- 100+ adet$20.11
- 500+ adet$18.97
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Gender
- Male
- Insulation Resistance
- 1GOhm
- Reach Svhc
- No SVHC
- Parça Durumu
- Active
- Frekans
- 10GHz
- Filter Feature
- NO
- Connector Type
- Plug, Male Pin
- Option
- GENERAL PURPOSE
- Insertion Loss
- 0.7dB
- Mating Cycles
- 12000
- Includes
- 2 pcs - 1 Connector, 1 Heat Shrink
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Seri
- MS-162
- Body Material
- Phosphor Bronze
- Contact Termination
- Solder
- Vswr
- 1.7
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2006
- Iec Conformance
- NO
- Center Contact Plating
- Gold
- Contact Materials
- Bronze, Copper
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Style
- Coaxial Switch - 4mm Plug Dia
- JESD-609 Kodu
- e4
- Contact Resistance
- 100mOhm
- Montaj
- Cable, Free Hanging
- Empedans
- 50Ohm
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Color
- Silver
- Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- Ambalaj
- Tray
- Din Conformance
- NO
- Cable Group
- 1.5D-HQEW
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Number Of Ports
- 1
- Özellikler
- Internal Switch
- Center Contact Material
- Phosphor Bronze
