MDF7P-6P-2.54DSA(01)

Teknik Özellikler

Durability

50 Cycles

ECCN Kodu

EAR99

REACH Uyumluluk Kodu

unknown

RoHS Durumu

RoHS Compliant

Contact Type

Male Pin

Insertion Forcemax

4.3924 N

Contact Length Post

0.118 3.00mm

Mixed Contacts

NO

Montaj Tipi

Through Hole

Sıra Sayısı

1

Overall Contact Length

0.710 18.03mm

Contact Lengthmating

0.492 12.50mm

Number Of Conductors

ONE

Shrouding

Unshrouded

Option

GENERAL PURPOSE

Insulation Materials

Polybutylene Terephthalate (PBT)

Terminal Adımı

2.54mm

Contact Finish Thickness Mating

8.00μin 0.203μm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Terminal

Solder

Ambalaj

Bulk

Material Flammability Rating

UL94 V-0

Parça Durumu

Active

Çalışma Sıcaklığı

-35°C~85°C

Pozisyon Sayısı

6

Insulation Color

Black

Din Conformance

NO

Connector Type

Header

Contact Finish Mating

Gold

Pitch Mating

0.100 2.54mm

Seri

MDF7

Nominal Gerilim

250V

Iec Conformance

NO

Contact Shape

Square

Fastening Type

Push-Pull

Reliability

COMMERCIAL

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Mil Conformance

NO

Number Of Positions Loaded

All

Reference Standard

UL
