Teknik Özellikler
- Contact Shape
- Square
- Dielectric Withstanding Voltage
- 650VAC V
- Filter Feature
- NO
- Sıra Sayısı
- 1
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Pozisyon Sayısı
- 9
- Contact Type
- Male Pin
- Number Of Conductors
- ONE
- Ambalaj
- Bulk
- Durability
- 50 Cycles
- Seri
- MDF7
- Terminal
- Solder
- Number Of Pcb Rows
- 1
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Connector Type
- Header
- Terminal Adımı
- 2.54mm
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Contact Finish Mating
- Gold
- Style
- Board to Board
- Pcb Contact Pattern
- RECTANGULAR
- Contact Length Post
- 0.118 3.00mm
- Insulation Color
- Black
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 250V
- Option
- GENERAL PURPOSE
- Iec Conformance
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Resistance
- 30mOhm
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Fastening Type
- Push-Pull
- Pitch Mating
- 0.100 2.54mm
- Çalışma Sıcaklığı
- -35°C~85°C
- Current Rating Amps
- 3A
- REACH Uyumluluk Kodu
- unknown
- Contact Materials
- Brass
- JESD-609 Kodu
- e4
- Fabrika Tedarik Süresi
- 10 Weeks
