JR21RK-16PC

Teknik Özellikler

Nem Hassasiyeti (MSL)

1 (Unlimited)

Montaj

Flanges, Panel

Contact Resistance

10mOhm

Body Breadth

1.26 inch

Din Conformance

NO

Rated Current Signal

3A

Shell Size Insert

21

Insert Material

Polycarbonate (PC)

Material Flammability Rating

UL94 V-0

Contact Shape

Circular

Contact Type

Crimp

Shell Material

Aluminum Alloy

REACH Uyumluluk Kodu

unknown

RoHS Durumu

RoHS Compliant

Seri

JR

Option

GENERAL PURPOSE

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Mounting Feature

Flange

Dielectric Withstanding Voltage

1000VAC V

Body Depth

1 inch

JESD-609 Kodu

e4

Çalışma Sıcaklığı

-25°C~85°C

Iec Conformance

NO

Body Length Or Diameter

1.26 inch

Reliability

COMMERCIAL

Fabrika Tedarik Süresi

8 Weeks

Kurşunsuz Kodu

yes

Fastening Type

Threaded

Tip

For Male Pins

Contact Materials

COPPER ALLOY

Total Number Of Contacts

16

Orientation

Keyed

Empty Shell

NO

Note

Contacts Not Included

Reference Standard

UL

Filter Feature

NO

Connector Type

Receptacle Housing

Shell Finish

Nickel

Shielding

Unshielded

Ambalaj

Bulk
