JR21PK-16P(71)

Teknik Özellikler

Çalışma Sıcaklığı

-25°C~85°C

Backshell Material Plating

Aluminum Alloy, Nickel

Pozisyon Sayısı

16

Body Depth

2.106 inch

Dielectric Withstanding Voltage

1000VAC V

Number Of Ports

1

Reach Svhc

No SVHC

Radyasyon Dayanımı

No

Insulation Resistance

1000000000Ohm

Kurşunsuz

Lead Free

Yayın Yılı

2009

Terminal

Solder Cup

Body Material

Aluminium

Montaj Tipi

Free Hanging (In-Line)

Özellikler

Backshell, Cable Clamp, Coupling Nut

Polarization Key

POLARIZED HOUSING

Contact Gender

Male

Parça Durumu

Active

Ambalaj

Bulk

Shielding

Unshielded

Contact Style

RND PIN-SKT

Seri

JR

Connector Type

Plug, Male Pins

Shell Finish

Nickel

Contact Finish Thickness Mating

118.1μin 3.00μm

RoHS Durumu

RoHS Compliant

Cable Opening

0.591 (15.00mm)

Shell Material

Aluminum Alloy

Akım Değeri

5A

Orientation

Keyed

Total Number Of Contacts

16

Nominal Gerilim

250VAC 350VDC

Durability

500 Cycles

Material Flammability Rating

UL94 V-0

Contact Materials

Copper Alloy

Shell Size Insert

21

Fastening Type

Threaded

Insert Material

Phenol Formaldehyde (PF)

Contact Finish Mating

Silver

Rated Current Signal

10A
