Adet bazlı fiyat
- 1+ adet$52.83
- 10+ adet$49.84
- 100+ adet$47.02
- 500+ adet$44.35
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Free Hanging (In-Line)
- Adapter Series
- BNC to SMA
- Contact Finish Mating
- NOT SPECIFIED
- Montaj
- Free Hanging
- Yayın Yılı
- 2004
- Adapter Type
- Plug to Jack
- Fastening Type
- Bayonet Lock, Threaded
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Style
- Straight
- Ambalaj
- Bulk
- Seri
- BWA
- Center Contact Plating
- Gold
- Vswr
- 1.05
- Frequencymax
- 4GHz
- Operating Temperature Min
- -40°C
- Mating Cycles
- 1000
- REACH Uyumluluk Kodu
- unknown
- Kılıf / Paket
- SMA
- Operating Frequency Max
- 12.4GHz
- Convert To Adapter End
- SMA Plug, Male Pin
- Body Plating
- Silver
- Fabrika Tedarik Süresi
- 10 Weeks
- ECCN Kodu
- EAR99
- Operating Temperature Max
- 85°C
- Center Contact Material
- Beryllium Copper
- Convert From Adapter End
- BNC Jack, Female Socket
- Body Finish
- Silver; Passivated
- Reliability
- COMMERCIAL
- Contact Materials
- Copper
- Center Gender
- Female to Male
- HTS Kodu
- 8536.69.80.00
- Conversion Type
- Between Series
- Body Material
- Brass; Stainless Steel
- Empedans
- 50Ohm
- Parça Durumu
- Active
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- RoHS Durumu
- RoHS Compliant
