Adet bazlı fiyat
- 1+ adet$26.47
- 10+ adet$24.97
- 100+ adet$23.56
- 500+ adet$22.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Empedans
- 50Ohm
- Dielectric Withstanding Voltage
- 1400VAC V
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Iec Conformance
- NO
- Convert From Adapter End
- SMA Jack, Female Socket
- Insertion Loss
- 0.13 dB
- Conversion Type
- Same Series
- HTS Kodu
- 8536.69.80.00
- Body Material
- Stainless Steel
- Mil Conformance
- YES
- Reliability
- COMMERCIAL
- Center Gender
- Female to Female
- Contact Materials
- Copper
- Mounting Feature
- Flange
- Vswr
- 1.17
- Mating Cycles
- 1000
- Frequencymax
- 18GHz
- Option
- GENERAL PURPOSE
- Seri
- HRM
- Insulation Materials
- TETRAFLUORIDE
- Center Contact Plating
- Gold
- Filter Feature
- NO
- ECCN Kodu
- EAR99
- Center Contact Material
- Beryllium Copper
- Convert To Adapter End
- SMA Jack, Female Socket
- Operating Frequency Max
- 12.4GHz
- Additional Feature
- STANDARD: MIL-C-39012
- REACH Uyumluluk Kodu
- unknown
- Kılıf / Paket
- SMA
- Fabrika Tedarik Süresi
- 12 Weeks
- Adapter Type
- Jack to Jack
- Yayın Yılı
- 2009
- Contact Finish Mating
- NOT SPECIFIED
- Adapter Series
- SMA to SMA
- Montaj Tipi
- Panel Mount
- Montaj
- Flanges, Panel
- Din Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
