Adet bazlı fiyat
- 1+ adet$5.15
- 10+ adet$4.85
- 100+ adet$4.58
- 500+ adet$4.32
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 10 Weeks
- Overall Contact Length
- 0.563 14.30mm
- Contact Materials
- Brass
- Current Rating Amps
- 0.5A
- Shrouding
- Shrouded - 4 Wall
- Seri
- HIF6
- Ul Flammability Code
- 94V-0
- Contact Type
- Male Pin
- Pozisyon Sayısı
- 50
- Mating Contact Pitch
- 0.05 inch
- Style
- Board to Cable/Wire
- REACH Uyumluluk Kodu
- unknown
- Akım Değeri
- 500mA
- Mil Conformance
- NO
- Number Of Conductors
- ONE
- Sıra Sayısı
- 2
- Row Spacing Mating
- 0.100 (2.54mm)
- Fastening Type
- Latch Lock/Eject Hooks
- Contact Lengthmating
- 0.205 5.21mm
- Terminal
- Solder
- Mixed Contacts
- NO
- Iec Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Filter Feature
- NO
- Contact Finish Mating
- Gold
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Pcb Contact Pattern
- STAGGERED
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Number Of Pcb Rows
- 4
- Reference Standard
- UL
- Ambalaj
- Tray
- Kurşunsuz
- Lead Free
- Connector Type
- Header
- Polarization Key
- GUIDE SLOT(S)
- Contact Resistance
- 30mOhm
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- RoHS Durumu
- RoHS Compliant
- Contact Finish Post
- Tin
- Length Termination
- 0.11 inch
