Adet bazlı fiyat
- 1+ adet$4.34
- 10+ adet$4.09
- 100+ adet$3.86
- 500+ adet$3.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Sıra Sayısı
- 2
- Number Of Conductors
- ONE
- Contact Lengthmating
- 0.205 5.21mm
- Terminal
- Solder
- Fastening Type
- Latch Lock/Eject Hooks
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Gender
- Male
- Mil Conformance
- NO
- Akım Değeri
- 500mA
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Mixed Contacts
- NO
- Iec Conformance
- NO
- Seri
- HIF6
- Shrouding
- Shrouded - 4 Wall
- Contact Materials
- Brass
- Current Rating Amps
- 0.5A
- Ul Flammability Code
- 94V-0
- Overall Contact Length
- 0.563 14.30mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Style
- Board to Cable/Wire
- REACH Uyumluluk Kodu
- unknown
- Mating Contact Pitch
- 0.05 inch
- Pozisyon Sayısı
- 34
- Contact Type
- Male Pin
- Housing Material
- PBT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Contact Length Post
- 0.110 2.79mm
- Montaj Tipi
- Through Hole
- Insulation Color
- Black
- Insulation Height
- 0.606 15.39mm
- Nominal Gerilim
- 300V
- Number Of Positions Loaded
- All
- Pitch Mating
- 0.050 1.27mm
- Mounting Option1
- LATCH & EJECT
- ECCN Kodu
- EAR99
- Option
- GENERAL PURPOSE
- Çalışma Sıcaklığı
- -55°C~85°C
