Adet bazlı fiyat
- 1+ adet$4.01
- 10+ adet$3.78
- 100+ adet$3.57
- 500+ adet$3.37
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Number Of Positions Loaded
- All
- Contact Finish Mating
- Gold
- Terminal
- Solder
- Kurşunsuz
- Lead Free
- Ambalaj
- Tray
- Contact Finish Post
- Tin
- Nominal Gerilim
- 300V
- Fastening Type
- Push-Pull
- Option
- GENERAL PURPOSE
- Din Conformance
- NO
- Sıra Sayısı
- 2
- Mixed Contacts
- NO
- Contact Type
- Male Pin
- Ul Flammability Code
- 94V-0
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Mil Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Contact Materials
- Brass
- REACH Uyumluluk Kodu
- unknown
- Connector Type
- Header
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Filter Feature
- NO
- Seri
- HIF6
- Pozisyon Sayısı
- 50
- Insulation Color
- Black
- Style
- Board to Board
- Akım Değeri
- 500mA
- Contact Lengthmating
- 0.205 5.21mm
- Shrouding
- Shrouded - 4 Wall
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Iec Conformance
- NO
- Current Rating Amps
- 0.5A
- Contact Shape
- Square
- Pitch Mating
- 0.050 1.27mm
- Montaj Tipi
- Through Hole
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Contact Length Post
- 0.110 2.79mm
- Contact Finish Thickness Post
- 78.7μin 2.00μm
