Adet bazlı fiyat
- 1+ adet$6.60
- 10+ adet$6.23
- 100+ adet$5.88
- 500+ adet$5.55
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Depth
- 0.453 inch
- Insulation Color
- Black
- Contact Lengthmating
- 0.205 5.21mm
- Shrouding
- Shrouded - 4 Wall
- Contact Gender
- Male
- Fabrika Tedarik Süresi
- 10 Weeks
- Seri
- HIF6
- Number Of Conductors
- ONE
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Insulation Height
- 0.453 11.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Shape
- Square
- Current Rating Amps
- 0.5A
- Contact Length Post
- 0.110 2.79mm
- Montaj Tipi
- Through Hole
- Pitch Mating
- 0.050 1.27mm
- Nominal Gerilim
- 300V
- Pcb Contact Row Spacing
- 1.905 mm
- Contact Finish Post
- Tin
- Pcb Contact Pattern
- STAGGERED
- Sıra Sayısı
- 2
- Contact Finish Mating
- Gold
- Contact Resistance
- 30mOhm
- Contact Materials
- Brass
- Reference Standard
- UL
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 1GOhm
- Number Of Pcb Rows
- 4
- Pozisyon Sayısı
- 100
- Akım Değeri
- 500mA
- Style
- Board to Board
- Connector Type
- Header
- Çalışma Sıcaklığı
- -55°C~85°C
- Reliability
- COMMERCIAL
- Length Termination
- 0.11 inch
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Mounting Option1
- LOCKING
