Adet bazlı fiyat
- 1+ adet$4.84
- 10+ adet$4.56
- 100+ adet$4.31
- 500+ adet$4.06
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pcb Contact Pattern
- STAGGERED
- Option
- GENERAL PURPOSE
- Sıra Sayısı
- 2
- Pcb Contact Row Spacing
- 1.905 mm
- Contact Finish Post
- Tin
- Nominal Gerilim
- 300V
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
- Contact Finish Mating
- Gold
- Number Of Pcb Rows
- 4
- Insulation Resistance
- 1000000000Ohm
- Contact Materials
- Brass
- Reference Standard
- UL
- REACH Uyumluluk Kodu
- unknown
- Mil Conformance
- NO
- Contact Lengthmating
- 0.217 5.50mm
- Shrouding
- Shrouded - 4 Wall
- Insulation Color
- Black
- JESD-609 Kodu
- e4
- Body Depth
- 0.768 inch
- Orientation
- Right Angle
- Number Of Conductors
- ONE
- Seri
- HIF6
- Fabrika Tedarik Süresi
- 10 Weeks
- Insulation Height
- 0.335 8.51mm
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Row Spacing Mating
- 0.100 (2.54mm)
- HTS Kodu
- 8536.69.40.40
- Current Rating Amps
- 0.5A
- Contact Shape
- Square
- Pitch Mating
- 0.050 1.27mm
- Montaj Tipi
- Through Hole, Right Angle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Fastening Type
- Latch Lock/Eject Hooks
- Din Conformance
- NO
- Polarization Key
- POLARIZED HOUSING
- Kurşunsuz
- Lead Free
- Ambalaj
- Tray
- Body Breadth
- 0.344 inch
