Adet bazlı fiyat
- 1+ adet$3.49
- 10+ adet$3.30
- 100+ adet$3.11
- 500+ adet$2.93
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.217 5.50mm
- Body Depth
- 0.768 inch
- Insulation Color
- Black
- Seri
- HIF6
- Number Of Conductors
- ONE
- Fabrika Tedarik Süresi
- 10 Weeks
- Insulation Height
- 0.335 8.51mm
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Pitch Mating
- 0.050 1.27mm
- Montaj Tipi
- Through Hole, Right Angle
- Contact Shape
- Square
- Current Rating Amps
- 0.5A
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Pcb Contact Pattern
- STAGGERED
- Nominal Gerilim
- 300V
- Contact Finish Post
- Tin
- Pcb Contact Row Spacing
- 1.905 mm
- Contact Resistance
- 30mOhm
- Contact Finish Mating
- Gold
- Insulation Resistance
- 1000000000Ohm
- Number Of Pcb Rows
- 4
- REACH Uyumluluk Kodu
- unknown
- Reference Standard
- UL
- Contact Materials
- Brass
- Total Number Of Contacts
- 26
- Akım Değeri
- 500mA
- Style
- Board to Cable/Wire
- Pozisyon Sayısı
- 26
- Reliability
- COMMERCIAL
- Çalışma Sıcaklığı
- -55°C~85°C
- Body Length Or Diameter
- 1.369 inch
- Connector Type
- Header
- Parça Durumu
- Active
- Özellikler
- Keying Slot, Mounting Flange
- Length Termination
- 0.11 inch
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
