Teknik Özellikler
- Number Of Positions Loaded
- All
- Mounting Option2
- LOCKING
- Number Of Conductors
- ONE
- Contact Length Post
- 0.130 3.30mm
- Dielectric Withstanding Voltage
- 650VAC V
- Mounting Option1
- LATCH & EJECT
- Contact Resistance
- 15mOhm
- Contact Materials
- Brass
- Pitch Mating
- 0.100 2.54mm
- Insulation Color
- Black
- Pcb Contact Pattern
- RECTANGULAR
- Insulation Height
- 0.701 17.80mm
- Contact Shape
- Square
- Filter Feature
- NO
- ECCN Kodu
- EAR99
- Connector Type
- Header
- Montaj Tipi
- Through Hole
- Overall Contact Length
- 0.657 16.70mm
- Contact Type
- Male Pin
- Terminal
- Solder
- Row Spacing Mating
- 0.100 (2.54mm)
- Seri
- HIF3B
- Insulation Resistance
- 1GOhm
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Fastening Type
- Latch Lock/Eject Hooks
- Contact Finish Post
- Tin
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Fabrika Tedarik Süresi
- 10 Weeks
- Din Conformance
- NO
- Orientation
- Straight
- Material Flammability Rating
- UL94 V-0
- JESD-609 Kodu
- e4
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Reference Standard
- UL
- Radyasyon Dayanımı
- No
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Polarization Key
- POLARIZED HOUSING
