Adet bazlı fiyat
- 1+ adet$0.97
- 10+ adet$0.92
- 100+ adet$0.87
- 500+ adet$0.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Connector Type
- Header
- Shrouding
- Shrouded - 4 Wall
- Number Of Positions Loaded
- All
- Montaj
- Surface Mount
- Montaj Tipi
- Surface Mount
- Renk
- Grey
- Number Of Pcb Rows
- 2
- Mating Contact Pitch
- 0.087 inch
- Fabrika Tedarik Süresi
- 10 Weeks
- REACH Uyumluluk Kodu
- unknown
- Contact Materials
- Brass
- HTS Kodu
- 8536.69.40.30
- Seri
- GT25
- Current Rating Amps
- 3A
- Terminal
- Solder
- Çalışma Sıcaklığı
- -40°C~105°C
- Ambalaj
- Tray
- Insulation Height
- 0.740 18.80mm
- Contact Finish Mating
- Tin
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Contact Lengthmating
- 0.220 5.59mm
- Dielectric Withstanding Voltage
- 650VAC V
- Insulation Color
- Gray
- Pcb Contact Pattern
- RECTANGULAR
- Contact Shape
- Square
- Contact Length Post
- 0.055 1.40mm
- Style
- Board to Cable/Wire
- Row Spacing Mating
- 0.118 (3.00mm)
- Özellikler
- Solder Retention
- Pitch Mating
- 0.087 2.20mm
- Number Of Conductors
- ONE
- Contact Type
- Male Pin
- Fastening Type
- Latch Holder
- Reliability
- COMMERCIAL
- Contact Resistance
- 30mOhm
- Insulation Materials
- Polyphenylene Sulfide (PPS)
- Pozisyon Sayısı
- 16
