Adet bazlı fiyat
- 1+ adet$2.90
- 10+ adet$2.74
- 100+ adet$2.58
- 500+ adet$2.43
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Phosphor Bronze
- Pitch
- 0.010 0.25mm
- Actuatorcolor
- Black
- Flat Flex Type
- FPC
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -55°C~85°C
- Nominal Gerilim
- 30V
- Seri
- FH64MA
- Parça Durumu
- Active
- Height Above Board
- 0.020 0.50mm
- Housing Color
- Beige
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Cut Tape (CT)
- Actuator Material
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 19
- Contact Finish
- Gold
- Terminal
- Solder
- Mating Cycles
- 10
- Locking Feature
- Flip Lock, Backlock
- Current Rating Amps
- 0.2A
- Contact Finish Thickness
- 1.18μin 0.030μm
- Ffc Fcb Thickness
- 0.12mm
- Cable End Type
- Notched
- Fabrika Tedarik Süresi
- 10 Weeks
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Surface Mount, Right Angle
