Adet bazlı fiyat
- 1+ adet$0.26
- 10+ adet$0.25
- 100+ adet$0.24
- 500+ adet$0.22
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Akım Değeri
- 500mA
- Actuatorcolor
- Black
- Flat Flex Type
- FFC, FPC
- Pitch
- 0.020 0.50mm
- Contact Materials
- Phosphor Bronze
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Seri
- FH52
- Çalışma Sıcaklığı
- -40°C~105°C
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Ambalaj
- Tape & Reel (TR)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Height Above Board
- 0.079 2.00mm
- Housing Color
- Gray
- Pozisyon Sayısı
- 8
- Contact Finish
- Gold
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Mating Cycles
- 20
- Locking Feature
- Flip Lock
- Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Contact Location
- Bottom
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- unknown
- Current Rating Amps
- 0.5A
- Contact Finish Thickness
- 1.18μin 0.030μm
- Cable End Type
- Tabbed
- Ffc Fcb Thickness
- 0.30mm
- Material Flammability Rating
- UL94 V-0
- Montaj
- Surface Mount
- Montaj Tipi
- Surface Mount, Right Angle
