Adet bazlı fiyat
- 1+ adet$2.62
- 10+ adet$2.47
- 100+ adet$2.33
- 500+ adet$2.20
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pozisyon Sayısı
- 28
- Contact Finish
- Gold
- Body Breadth
- 0.079 inch
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Reference Standard
- UL
- Mating Cycles
- 20
- Locking Feature
- Flip Lock
- Flammability Rating
- UL94 V-0
- Number Of Pcb Rows
- 1
- Terminal
- Solder
- ECCN Kodu
- EAR99
- Contact Location
- Bottom
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 500000000Ohm
- Contact Finish Thickness
- 1.18μin 0.030μm
- Current Rating Amps
- 0.5A
- Orientation
- Right Angle
- Ffc Fcb Thickness
- 0.30mm
- Gender
- Female
- HTS Kodu
- 8536.69.40.40
- Cable End Type
- Tabbed
- Connector Type
- FFC/FPC CONNECTOR
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Surface Mount, Right Angle
- Total Number Of Contacts
- 28
- Actuatorcolor
- Black
- Akım Değeri
- 500mA
- Flat Flex Type
- FFC, FPC
- Contact Materials
- Phosphor Bronze
- Pitch
- 0.020 0.50mm
- Contact Pattern
- RECTANGULAR
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Sıra Sayısı
- 1
- Contact Resistance
- 50mOhm
- Nominal Gerilim
- 50V
- Çalışma Sıcaklığı
- -40°C~105°C
- Seri
- FH52
- Parça Durumu
- Active
