Adet bazlı fiyat
- 1+ adet$2.86
- 10+ adet$2.70
- 100+ adet$2.55
- 500+ adet$2.40
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- HTS Kodu
- 8536.69.40.40
- Connector Type
- FFC/FPC CONNECTOR
- Gender
- Receptacle
- Orientation
- Right Angle
- Insulation Resistance
- 500000000Ohm
- REACH Uyumluluk Kodu
- unknown
- Total Number Of Contacts
- 18
- Montaj
- Surface Mount
- Contact Finish
- Gold
- Contact Style
- BELLOWED TYPE
- Seri
- FH52
- Reliability
- COMMERCIAL
- Housing Color
- Gray
- Pcb Contact Pattern
- RECTANGULAR
- Body Depth
- 0.224 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Actuatorcolor
- Black
- Contact Resistance
- 50mOhm
- Sıra Sayısı
- 1
- Cable End Type
- Tabbed
- Ffc Fcb Thickness
- 0.30mm
- Current Rating Amps
- 0.5A
- Contact Finish Thickness
- 1.18μin 0.030μm
- Montaj Tipi
- Surface Mount, Right Angle
- Material Flammability Rating
- UL94 V-0
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Body Breadth
- 0.079 inch
- Pozisyon Sayısı
- 18
- Contact Location
- Bottom
- ECCN Kodu
- EAR99
- Terminal
- Solder
- Number Of Pcb Rows
- 1
- Flammability Rating
- UL94 V-0
- Locking Feature
- Flip Lock
- Reference Standard
- UL
- Mating Cycles
- 20
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~105°C
