Teknik Özellikler
- Montaj Tipi
- Surface Mount, Right Angle
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Total Number Of Contacts
- 15
- Insulation Resistance
- 500000000Ohm
- REACH Uyumluluk Kodu
- unknown
- Gender
- Receptacle
- Ffc Fcb Thickness
- 0.30mm
- HTS Kodu
- 8536.69.40.40
- Cable End Type
- Tabbed
- Connector Type
- FFC/FPC CONNECTOR
- Contact Finish Thickness
- 1.18μin 0.030μm
- Current Rating Amps
- 0.5A
- Orientation
- Right Angle
- Flammability Rating
- UL94 V-0
- Locking Feature
- Flip Lock
- Mating Cycles
- 20
- Reference Standard
- UL
- ECCN Kodu
- EAR99
- Contact Location
- Bottom
- Number Of Pcb Rows
- 1
- Terminal
- Solder
- Contact Finish
- Gold
- Pozisyon Sayısı
- 15
- Body Breadth
- 0.079 inch
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Cut Tape (CT)
- Housing Color
- Gray
- Pcb Contact Pattern
- RECTANGULAR
- Reliability
- COMMERCIAL
- Body Depth
- 0.224 inch
- Height Above Board
- 0.079 2.00mm
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~105°C
- Nominal Gerilim
- 50V
- Seri
- FH52
- Contact Style
- BELLOWED TYPE
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 50mOhm
