Teknik Özellikler
- ECCN Kodu
- EAR99
- Number Of Pcb Rows
- 2
- Terminal
- Solder
- Flammability Rating
- UL94 V-0
- Locking Feature
- Flip Lock
- Reference Standard
- UL
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Durability
- 20 Cycles
- Wirecable Type
- Flat Flex
- Pozisyon Sayısı
- 50
- Total Number Of Contacts
- 50
- Fabrika Tedarik Süresi
- 10 Weeks
- Montaj Tipi
- Surface Mount
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Gender
- Female
- Ffc Fcb Thickness
- 0.30mm
- HTS Kodu
- 8536.69.40.51
- Cable End Type
- Tabbed
- Current Rating Amps
- 0.5A
- REACH Uyumluluk Kodu
- unknown
- Contact Resistance
- 100mOhm
- Sıra Sayısı
- 1
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Contact Plating
- Gold
- RoHS Durumu
- RoHS Compliant
- Özellikler
- Low Insertion Force (LIF)
- Contact Materials
- Phosphor Bronze
- Contact Pattern
- RECTANGULAR
- Pitch
- 0.020 0.50mm
- Flat Flex Type
- FFC
- Actuatorcolor
- Black
- Akım Değeri
- 500mA
- Pcb Contact Pattern
- STAGGERED
- Housing Color
- Gray
- Reliability
- COMMERCIAL
- Height Above Board
- 0.243 6.18mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tape & Reel (TR)
- Dielectric Withstanding Voltage
- 200VAC V
