Adet bazlı fiyat
- 1+ adet$0.86
- 10+ adet$0.81
- 100+ adet$0.76
- 500+ adet$0.72
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Surface Mount
- Total Number Of Contacts
- 40
- Fabrika Tedarik Süresi
- 10 Weeks
- Insulation Resistance
- 500000000Ohm
- Max Current Rating
- 500mA
- Current Rating Amps
- 0.5A
- Orientation
- Straight
- Gender
- Receptacle
- Ffc Fcb Thickness
- 0.30mm
- Depth
- 4.7mm
- Cable End Type
- Tabbed
- Uzunluk
- 25mm
- Reference Standard
- UL
- Flammability Rating
- UL94 V-0
- Locking Feature
- Flip Lock
- Number Of Pcb Rows
- 2
- Terminal
- Solder
- ECCN Kodu
- EAR99
- Pozisyon Sayısı
- 40
- Reach Svhc
- No SVHC
- Wirecable Type
- Flat Flex
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tape & Reel (TR)
- Height Above Board
- 0.243 6.18mm
- Housing Color
- Gray
- Pcb Contact Pattern
- STAGGERED
- Reliability
- COMMERCIAL
- Çalışma Sıcaklığı
- -40°C~85°C
- Pcb Contact Row Spacing
- 3.7846 mm
- Seri
- FH48
- Parça Durumu
- Active
- Contact Style
- BELLOWED TYPE
- RoHS Durumu
- RoHS Compliant
- Contact Plating
- Gold
- Max Voltage Rating Ac
- 50V
- Sıra Sayısı
- 2
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
