Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 10 Weeks
- Total Number Of Contacts
- 61
- Montaj
- Surface Mount
- Body Length Or Diameter
- 0.543 inch
- HTS Kodu
- 8536.69.40.40
- Connector Type
- BOARD CONNECTOR
- Gender
- Female
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 50000000Ohm
- Contact Finish
- Gold
- Body Depth
- 0.112 inch
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- STAGGERED
- Housing Color
- Beige
- Dielectric Withstanding Voltage
- 90VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Style
- BELLOWED TYPE
- Seri
- FH43B
- Sıra Sayısı
- 1
- Contact Materials
- Phosphor Bronze
- Özellikler
- Zero Insertion Force (ZIF)
- Actuatorcolor
- Black
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Surface Mount, Right Angle
- Current Rating Amps
- 0.2A
- Cable End Type
- Tabbed
- Ffc Fcb Thickness
- 0.20mm
- Terminal
- Solder
- Number Of Pcb Rows
- 2
- ECCN Kodu
- EAR99
- Reference Standard
- UL
- Mating Cycles
- 10
- Flammability Rating
- UL94 V-0
- Locking Feature
- Flip Lock
- Body Breadth
- 0.035 inch
- Actuator Material
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 61
- Height Above Board
- 0.035 0.88mm
- Ambalaj
- Cut Tape (CT)
- Nominal Gerilim
- 30V
