Teknik Özellikler
- Ul Flammability Code
- 94V-0
- Orientation
- Right Angle
- Gender
- Receptacle
- Kurşunsuz Kodu
- yes
- Montaj
- Surface Mount
- Mil Conformance
- NO
- Iec Conformance
- NO
- Total Number Of Contacts
- 50
- Reach Svhc
- No SVHC
- Contact Finish
- Gold
- Wirecable Type
- Flat Flex
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Seri
- FH41
- Contact Style
- BELLOWED TYPE
- Din Conformance
- NO
- Nem Hassasiyeti (MSL)
- 2A (4 Weeks)
- Body Depth
- 0.244 inch
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- RECTANGULAR
- Housing Color
- Gray
- Actuatorcolor
- Black
- JESD-609 Kodu
- e3
- Contact Materials
- Phosphor Bronze
- Özellikler
- Solder Retention
- Sıra Sayısı
- 1
- Additional Feature
- SHIELDED
- Contact Finish Thickness
- 1.18μin 0.030μm
- Current Rating Amps
- 0.5A
- Cable End Type
- Tabbed
- Ffc Fcb Thickness
- 0.30mm
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Surface Mount, Right Angle
- Pozisyon Sayısı
- 50
- Radyasyon Dayanımı
- No
- Body Breadth
- 0.098 inch
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Mating Cycles
- 20
- Reference Standard
- UL
- Locking Feature
- Flip Lock, Backlock
