Adet bazlı fiyat
- 1+ adet$0.37
- 10+ adet$0.35
- 100+ adet$0.33
- 500+ adet$0.31
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Filter Feature
- NO
- Number Of Pcb Rows
- 2
- Terminal
- Solder
- ECCN Kodu
- EAR99
- Reference Standard
- UL
- Mating Cycles
- 10
- Flammability Rating
- UL94 HB
- Locking Feature
- Flip Lock
- Actuator Material
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 51
- Material Flammability Rating
- UL94 HB
- Montaj Tipi
- Surface Mount, Right Angle
- Current Rating Amps
- 0.2A
- Contact Finish Thickness
- 19.7μin 0.50μm
- Ffc Fcb Thickness
- 0.20mm
- Cable End Type
- Tabbed
- Additional Feature
- LOW PROFILE
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- RoHS Durumu
- RoHS Compliant
- Pitch
- 0.012 0.30mm
- Contact Pattern
- STAGGERED
- Akım Değeri
- 200mA
- Flat Flex Type
- FPC
- Height Above Board
- 0.039 1.00mm
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Lead Free
- Nominal Gerilim
- 30V
- Çalışma Sıcaklığı
- -55°C~85°C
- Parça Durumu
- Active
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Contact Finish
- Gold
- Fabrika Tedarik Süresi
- 10 Weeks
- Iec Conformance
- NO
- Total Number Of Contacts
- 51
- Mil Conformance
- NO
- Montaj
- Surface Mount
- Insulation Resistance
- 50MOhm
- REACH Uyumluluk Kodu
- unknown
- Sıra Sayısı
- 1
