Adet bazlı fiyat
- 1+ adet$1.57
- 10+ adet$1.48
- 100+ adet$1.40
- 500+ adet$1.32
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Material Flammability Rating
- UL94 HB
- Montaj Tipi
- Surface Mount, Right Angle
- Additional Feature
- LOW PROFILE
- Contact Finish Thickness
- 19.7μin 0.50μm
- Current Rating Amps
- 0.2A
- Cable End Type
- Tabbed
- Ffc Fcb Thickness
- 0.20mm
- Mating Cycles
- 10
- Reference Standard
- UL
- Locking Feature
- Flip Lock
- Flammability Rating
- UL94 HB
- Terminal
- Solder
- Filter Feature
- NO
- Number Of Pcb Rows
- 2
- ECCN Kodu
- EAR99
- Pozisyon Sayısı
- 31
- Actuator Material
- Polyamide (PA), Nylon
- Ambalaj
- Tape & Reel (TR)
- Height Above Board
- 0.039 1.00mm
- Nominal Gerilim
- 30V
- Çalışma Sıcaklığı
- -55°C~85°C
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Akım Değeri
- 200mA
- Flat Flex Type
- FPC
- Pitch
- 0.012 0.30mm
- Contact Pattern
- STAGGERED
- Montaj
- Surface Mount
- Mil Conformance
- NO
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 10 Weeks
- Total Number Of Contacts
- 31
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 50MOhm
- HTS Kodu
- 8536.69.40.51
- Mixed Contacts
- NO
- Contact Finish
- Gold
- Option
- GENERAL PURPOSE
- Din Conformance
- NO
