Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pcb Contact Pattern
- STAGGERED
- Housing Color
- Beige
- Reliability
- COMMERCIAL
- Height Above Board
- 0.039 1.00mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 120VAC V
- Ambalaj
- Cut Tape (CT)
- Contact Style
- BELLOWED TYPE
- Parça Durumu
- Discontinued
- Nominal Gerilim
- 30V
- Çalışma Sıcaklığı
- -55°C~85°C
- Pcb Contact Row Spacing
- 2.3622 mm
- Seri
- FH36
- Sıra Sayısı
- 1
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- RoHS Durumu
- RoHS Compliant
- Insertion Forcemax
- ZIF N
- Özellikler
- Zero Insertion Force (ZIF)
- Contact Materials
- Phosphor Bronze
- Pitch
- 0.012 0.30mm
- Contact Pattern
- RECTANGULAR
- Flat Flex Type
- FPC
- Actuatorcolor
- Brown
- Akım Değeri
- 200mA
- Total Number Of Contacts
- 27
- Montaj Tipi
- Surface Mount, Right Angle
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 HB
- Ffc Fcb Thickness
- 0.20mm
- Gender
- Female
- Cable End Type
- Tabbed
- Current Rating Amps
- 0.2A
- Body Length Or Diameter
- 0.382 inch
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 50000000Ohm
- Number Of Pcb Rows
- 2
- Terminal
- Solder
- Flammability Rating
- UL94 HB
- Locking Feature
- Flip Lock
- Reference Standard
- UL
