Adet bazlı fiyat
- 1+ adet$2.48
- 10+ adet$2.34
- 100+ adet$2.21
- 500+ adet$2.08
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Flammability Rating
- UL94 HB
- Locking Feature
- Flip Lock
- Mating Cycles
- 10
- Reference Standard
- UL
- Number Of Pcb Rows
- 2
- Terminal
- Solder
- Contact Finish
- Gold
- Pozisyon Sayısı
- 19
- Body Breadth
- 0.039 inch
- Actuator Material
- Polyamide (PA), Nylon
- Montaj Tipi
- Surface Mount, Right Angle
- Montaj
- Surface Mount
- Material Flammability Rating
- UL94 HB
- Total Number Of Contacts
- 19
- Fabrika Tedarik Süresi
- 10 Weeks
- Insulation Resistance
- 50000000Ohm
- REACH Uyumluluk Kodu
- unknown
- Gender
- Female
- Ffc Fcb Thickness
- 0.20mm
- Cable End Type
- Tabbed
- Current Rating Amps
- 0.2A
- Body Length Or Diameter
- 0.287 inch
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Sıra Sayısı
- 1
- Flat Flex Type
- FPC
- Actuatorcolor
- Brown
- Akım Değeri
- 200mA
- Özellikler
- Zero Insertion Force (ZIF)
- Insertion Forcemax
- ZIF N
- Contact Materials
- Phosphor Bronze
- Pitch
- 0.012 0.30mm
- Contact Pattern
- RECTANGULAR
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Digi-Reel®
- Dielectric Withstanding Voltage
- 120VAC V
- Housing Color
- Beige
- Pcb Contact Pattern
- STAGGERED
- Reliability
- COMMERCIAL
- Height Above Board
- 0.039 1.00mm
