Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Locking Feature
- Flip Lock
- Contact Style
- BELLOWED TYPE
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Beige
- Parça Durumu
- Active
- Total Number Of Contacts
- 35
- Montaj
- Surface Mount
- Ambalaj
- Tape & Reel (TR)
- Cable End Type
- Tabbed
- Height Above Board
- 0.039 1.00mm
- Seri
- FH36
- Reference Standard
- UL
- Actuator Material
- Polyamide (PA), Nylon
- Number Of Pcb Rows
- 2
- Ffc Fcb Thickness
- 0.20mm
- Terminal
- Solder
- Özellikler
- Zero Insertion Force (ZIF)
- Montaj Tipi
- Surface Mount, Right Angle
- RoHS Durumu
- RoHS Compliant
- Insertion Forcemax
- ZIF N
- Contact Finish
- Gold
- Akım Değeri
- 200mA
- Flat Flex Type
- FPC
- Body Length Or Diameter
- 0.476 inch
- Actuatorcolor
- Brown
- Body Breadth
- 0.039 inch
- Mating Cycles
- 10
- REACH Uyumluluk Kodu
- unknown
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 1
- Nominal Gerilim
- 30V
- Pitch
- 0.012 0.30mm
- Pcb Contact Row Spacing
- 2.3622 mm
- Insulation Resistance
- 50000000Ohm
- Contact Materials
- Phosphor Bronze
- Flammability Rating
- UL94 V-0
- Housing Material
- Liquid Crystal Polymer (LCP)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 120VAC V
