Teknik Özellikler
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Pozisyon Sayısı
- 51
- Contact Finish Thickness
- 11.8μin 0.30μm
- Current Rating Amps
- 0.2A
- Pcb Contact Pattern
- STAGGERED
- Insulation Resistance
- 50MOhm
- Contact Materials
- Phosphor Bronze
- Pitch
- 0.012 0.30mm
- Pcb Contact Row Spacing
- 2.8702 mm
- Flammability Rating
- UL94 V-0
- Dielectric Withstanding Voltage
- 90VAC V
- Housing Material
- Liquid Crystal Polymer (LCP)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ffc Fcb Thickness
- 0.20mm
- Terminal
- Solder
- Number Of Pcb Rows
- 2
- Contact Location
- Dual
- Actuator Material
- Polyamide (PA), Nylon
- Voltage Rated Ac
- 30V
- Mating Cycles
- 10
- Body Breadth
- 0.035 inch
- Contact Pattern
- STAGGERED
- Sıra Sayısı
- 2
- REACH Uyumluluk Kodu
- unknown
- ECCN Kodu
- EAR99
- Contact Finish
- Gold
- Akım Değeri
- 200mA
- Montaj Tipi
- Surface Mount, Right Angle
- Insertion Forcemax
- ZIF N
- RoHS Durumu
- RoHS Compliant
- Body Length Or Diameter
- 0.665 inch
- Actuatorcolor
- Black
- Flat Flex Type
- FPC
- Housing Color
- Gray
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Contact Style
- BELLOWED TYPE
- Locking Feature
- Flip Lock, Backlock
