Teknik Özellikler
- Height Above Board
- 0.035 0.88mm
- Seri
- FH35C
- Cable End Type
- Tapered
- Ambalaj
- Tape & Reel (TR)
- Montaj
- Surface Mount
- Body Depth
- 0.132 inch
- Total Number Of Contacts
- 41
- Parça Durumu
- Active
- Housing Color
- Gray
- Material Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Contact Style
- BELLOWED TYPE
- Locking Feature
- Flip Lock, Backlock
- Sıra Sayısı
- 2
- Contact Pattern
- STAGGERED
- REACH Uyumluluk Kodu
- unknown
- Voltage Rated Ac
- 30V
- Body Breadth
- 0.035 inch
- Mating Cycles
- 10
- Actuatorcolor
- Black
- Body Length Or Diameter
- 0.547 inch
- Flat Flex Type
- FPC
- Akım Değeri
- 200mA
- Contact Finish
- Gold
- Montaj Tipi
- Surface Mount, Right Angle
- Insertion Forcemax
- ZIF N
- RoHS Durumu
- RoHS Compliant
- Terminal
- Solder
- Ffc Fcb Thickness
- 0.20mm
- Number Of Pcb Rows
- 2
- Contact Location
- Dual
- Actuator Material
- Polyamide (PA), Nylon
- Dielectric Withstanding Voltage
- 90VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Liquid Crystal Polymer (LCP)
- Flammability Rating
- UL94 V-0
- Contact Materials
- Phosphor Bronze
- Insulation Resistance
- 50MOhm
- Pitch
- 0.012 0.30mm
- Pcb Contact Row Spacing
- 2.8702 mm
