Teknik Özellikler
- Terminal
- Solder
- Ffc Fcb Thickness
- 0.20mm
- Actuator Material
- Polyamide (PA), Nylon
- Number Of Pcb Rows
- 2
- Contact Location
- Dual
- REACH Uyumluluk Kodu
- unknown
- Sıra Sayısı
- 2
- Contact Pattern
- STAGGERED
- Body Breadth
- 0.035 inch
- Mating Cycles
- 10
- Voltage Rated Ac
- 30V
- Flat Flex Type
- FPC
- Actuatorcolor
- Black
- Body Length Or Diameter
- 0.382 inch
- Montaj Tipi
- Surface Mount, Right Angle
- Insertion Forcemax
- ZIF N
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 200mA
- Contact Finish
- Gold
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Housing Color
- Gray
- Locking Feature
- Flip Lock, Backlock
- Contact Style
- BELLOWED TYPE
- Height Above Board
- 0.035 0.88mm
- Seri
- FH35C
- Cable End Type
- Tapered
- Ambalaj
- Tape & Reel (TR)
- Montaj
- Surface Mount
- Body Depth
- 0.132 inch
- Total Number Of Contacts
- 27
- Fabrika Tedarik Süresi
- 10 Weeks
- Pozisyon Sayısı
- 27
- Çalışma Sıcaklığı
- -55°C~85°C
- Contact Finish Thickness
- 11.8μin 0.30μm
- Pcb Contact Pattern
- STAGGERED
- Current Rating Amps
- 0.2A
- Flammability Rating
- UL94 V-0
- Pcb Contact Row Spacing
- 2.8702 mm
