Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- JESD-609 Kodu
- e4
- Flammability Rating
- UL94 HB
- Nominal Gerilim
- 50V
- Pitch
- 0.020 0.50mm
- Option
- GENERAL PURPOSE
- Insulation Resistance
- 500MOhm
- Contact Materials
- Phosphor Bronze
- Mil Conformance
- NO
- Connector Type
- FFC/FPC CONNECTOR
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gender
- Receptacle
- Pozisyon Sayısı
- 4
- Çalışma Sıcaklığı
- -55°C~85°C
- Wirecable Type
- Flat Flex
- Iec Conformance
- YES
- Current Rating Amps
- 0.5A
- Din Conformance
- NO
- Locking Feature
- Rotary Lock, Backlock
- Parça Durumu
- Obsolete
- Material Flammability Rating
- UL94 HB
- Housing Color
- Beige
- Montaj
- Surface Mount
- Reach Svhc
- Unknown
- Total Number Of Contacts
- 4
- Seri
- FH34SW
- Height Above Board
- 0.039 1.00mm
- Ambalaj
- Tape & Reel (TR)
- Cable End Type
- Tapered
- Actuator Material
- Polyamide (PA), Nylon, Halogen Free
- Terminal
- Solder
- Özellikler
- Zero Insertion Force (ZIF)
- Ffc Fcb Thickness
- 0.30mm
- Flat Flex Type
- FFC, FPC
- Actuatorcolor
- Black
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Surface Mount, Right Angle
- Akım Değeri
- 500mA
- Contact Finish
- Gold
- Kurşunsuz Kodu
- yes
