Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Connector Type
- FFC/FPC CONNECTOR
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 50V
- Pitch
- 0.020 0.50mm
- Insulation Resistance
- 500MOhm
- Contact Materials
- Phosphor Bronze
- Kurşunsuz
- Lead Free
- Wirecable Type
- Flat Flex
- Current Rating Amps
- 0.5A
- Gender
- Receptacle
- Contact Finish Thickness
- 1.97μin 0.050μm
- Fabrika Tedarik Süresi
- 10 Weeks
- Pozisyon Sayısı
- 30
- Çalışma Sıcaklığı
- -55°C~85°C
- Montaj
- Surface Mount
- Reach Svhc
- Unknown
- Height Above Board
- 0.039 1.00mm
- Seri
- FH34SRJ
- Ambalaj
- Tape & Reel (TR)
- Cable End Type
- Tapered
- Locking Feature
- Rotary Lock, Backlock
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Gray
- Flat Flex Type
- FFC, FPC
- Actuatorcolor
- Black
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Surface Mount, Right Angle
- ECCN Kodu
- EAR99
- Contact Finish
- Gold
- Akım Değeri
- 500mA
- Sıra Sayısı
- 1
- Mating Cycles
- 20
- Actuator Material
- Polyamide (PA), Nylon
- Terminal
- Solder
- Özellikler
- Zero Insertion Force (ZIF)
- Ffc Fcb Thickness
- 0.30mm
