Adet bazlı fiyat
- 1+ adet$0.85
- 10+ adet$0.80
- 100+ adet$0.76
- 500+ adet$0.72
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Locking Feature
- Flip Lock
- Parça Durumu
- Active
- Total Number Of Contacts
- 4
- Reach Svhc
- Unknown
- Cable End Type
- Tapered
- Reference Standard
- UL
- Terminal
- Solder
- Akım Değeri
- 500mA
- RoHS Durumu
- RoHS Compliant
- Body Length Or Diameter
- 0.256 inch
- Flat Flex Type
- FFC, FPC
- Filter Feature
- NO
- Mating Cycles
- 20
- Mixed Contacts
- NO
- Insulation Resistance
- 500MOhm
- Contact Materials
- Phosphor Bronze
- Pitch
- 0.039 1.00mm
- Option
- GENERAL PURPOSE
- Mil Conformance
- NO
- Kurşunsuz
- Lead Free
- Housing Material
- Polyamide (PA), Nylon
- Connector Type
- FFC/FPC CONNECTOR
- Contact Finish Thickness
- Flash
- Çalışma Sıcaklığı
- -55°C~85°C
- Pozisyon Sayısı
- 4
- Fabrika Tedarik Süresi
- 10 Weeks
- Wirecable Type
- Flat Flex
- Din Conformance
- NO
- Current Rating Amps
- 0.5A
- Pcb Contact Pattern
- RECTANGULAR
- Contact Style
- BELLOWED TYPE
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Body Depth
- 0.098 inch
- Montaj
- Surface Mount
- Ambalaj
- Tape & Reel (TR)
- Seri
- FH33
- Height Above Board
- 0.047 1.20mm
- Number Of Pcb Rows
- 1
- Actuator Material
- Polyamide (PA), Nylon
