Adet bazlı fiyat
- 1+ adet$0.95
- 10+ adet$0.89
- 100+ adet$0.84
- 500+ adet$0.80
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Locking Feature
- Flip Lock
- Cable End Type
- Tapered
- Total Number Of Contacts
- 26
- Reach Svhc
- Unknown
- Terminal
- Solder
- Reference Standard
- UL
- Filter Feature
- NO
- Mixed Contacts
- NO
- Mating Cycles
- 20
- Akım Değeri
- 500mA
- RoHS Durumu
- RoHS Compliant
- Flat Flex Type
- FFC, FPC
- Mil Conformance
- NO
- Kurşunsuz
- Lead Free
- Contact Materials
- Phosphor Bronze
- Insulation Resistance
- 500000000Ohm
- Pitch
- 0.020 0.50mm
- Option
- GENERAL PURPOSE
- Orientation
- Right Angle
- Housing Material
- Polyamide (PA), Nylon
- Connector Type
- FFC/FPC CONNECTOR
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Pozisyon Sayısı
- 26
- Contact Finish Thickness
- Flash
- Din Conformance
- NO
- Lead Pitch
- 500μm
- Current Rating Amps
- 0.5A
- Material Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Ambalaj
- Tape & Reel (TR)
- Height Above Board
- 0.047 1.20mm
- Seri
- FH33
- Montaj
- Surface Mount
- Ffc Fcb Thickness
- 0.30mm
- Ul Flammability Code
- 94V-0
- Özellikler
- Zero Insertion Force (ZIF)
- Number Of Pcb Rows
- 1
- Actuator Material
- Polyamide (PA), Nylon
