Teknik Özellikler
- Total Number Of Contacts
- 50
- Montaj
- Surface Mount
- Body Depth
- 0.252 inch
- Reach Svhc
- Unknown
- Rated Current Signal
- 0.5A
- Ambalaj
- Tape & Reel (TR)
- Cable End Type
- Tabbed
- Seri
- FH28
- Height Above Board
- 0.100 2.54mm
- Contact Style
- BELLOWED TYPE
- Locking Feature
- Rotary Lock
- Housing Color
- Gray
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Contact Finish
- Gold
- ECCN Kodu
- EAR99
- Akım Değeri
- 500mA
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Surface Mount, Right Angle
- Actuatorcolor
- Black
- Flat Flex Type
- FFC, FPC
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 1
- Reference Standard
- UL
- Number Of Pcb Rows
- 1
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Ffc Fcb Thickness
- 0.30mm
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Terminal
- Solder
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- FFC/FPC CONNECTOR
- Dielectric Withstanding Voltage
- 200VAC V
- Insulation Resistance
- 500MOhm
- Contact Materials
- Phosphor Bronze
- Nominal Gerilim
- 50V
- Pitch
- 0.020 0.50mm
- Orientation
- Right Angle
- Flammability Rating
- UL94 V-0
