Teknik Özellikler
- Pozisyon Sayısı
- 40
- Fabrika Tedarik Süresi
- 10 Weeks
- Çalışma Sıcaklığı
- -40°C~105°C
- Wirecable Type
- Flat Flex
- Pcb Contact Pattern
- RECTANGULAR
- Durability
- 20 Cycles
- Flammability Rating
- UL94 V-0
- Pitch
- 0.020 0.50mm
- Nominal Gerilim
- 50V
- Contact Materials
- Phosphor Bronze
- Insulation Resistance
- 500MOhm
- Connector Type
- FFC/FPC CONNECTOR
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 200VAC V
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Number Of Pcb Rows
- 1
- Reference Standard
- UL
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Terminal
- Solder
- Ffc Fcb Thickness
- 0.30mm
- Flat Flex Type
- FFC, FPC
- Actuatorcolor
- Black
- Body Length Or Diameter
- 0.968 inch
- Montaj Tipi
- Surface Mount, Right Angle
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 500mA
- Contact Finish
- Gold
- ECCN Kodu
- EAR99
- Contact Resistance
- 50mOhm
- REACH Uyumluluk Kodu
- unknown
- Sıra Sayısı
- 1
- Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.1 inch
- Locking Feature
- Rotary Lock
- Contact Style
- BELLOWED TYPE
- Parça Durumu
- Active
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Gray
