Teknik Özellikler
- Current Rating Amps
- 0.5A
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Sıra Sayısı
- 1
- Cable End Type
- Tabbed
- Contact Pattern
- RECTANGULAR
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Gray
- Din Conformance
- NO
- Flat Flex Type
- FFC, FPC
- Pozisyon Sayısı
- 10
- Seri
- FH28
- Montaj Tipi
- Surface Mount, Right Angle
- Filter Feature
- NO
- Ul Flammability Code
- 94V-0
- Pcb Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.1 inch
- Mounting Option1
- LOCKING
- JESD-609 Kodu
- e3
- Option
- GENERAL PURPOSE
- Contact Style
- BELLOWED TYPE
- Akım Değeri
- 500mA
- Reference Standard
- UL
- Additional Feature
- ZIF
- Body Length Or Diameter
- 0.389 inch
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Number Of Pcb Rows
- 1
- Kurşunsuz Kodu
- yes
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Phosphor Bronze
- Contact Finish
- Gold
- Fabrika Tedarik Süresi
- 12 Weeks
- Ffc Fcb Thickness
- 0.30mm
- REACH Uyumluluk Kodu
- unknown
- Body Depth
- 0.252 inch
- Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Wirecable Type
- Flat Flex
- Mating Cycles
- 20
