Adet bazlı fiyat
- 1+ adet$2.03
- 10+ adet$1.92
- 100+ adet$1.81
- 500+ adet$1.71
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Height Above Board
- 0.049 1.25mm
- Terminal
- Solder
- Locking Feature
- Flip Lock
- Mil Conformance
- NO
- Insertion Forcemax
- LIF N
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -55°C~85°C
- Actuatorcolor
- Black
- Voltage Rated Ac
- 30V
- Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Mating Cycles
- 10
- Montaj
- Surface Mount
- Ffc Fcb Thickness
- 0.20mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Parça Durumu
- Active
- Total Number Of Contacts
- 61
- Pitch
- 0.012 0.30mm
- Mixed Contacts
- NO
- Insulation Resistance
- 50000000Ohm
- Additional Feature
- STAGGERED CONFIGURATION, LIF, ZIF
- Reference Standard
- UL
- Akım Değeri
- 300mA
- Option
- GENERAL PURPOSE
- Genişlik
- 4.7mm
- Contact Finish
- Gold
- Reach Svhc
- No SVHC
- Contact Materials
- Phosphor Bronze
- Gender
- Receptacle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Number Of Pcb Rows
- 2
- Kurşunsuz Kodu
- yes
- Özellikler
- Low Insertion Force (LIF)
- Contact Pattern
- STAGGERED
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Cable End Type
- Tapered
- Sıra Sayısı
- 1
