Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Obsolete
- Mixed Contacts
- NO
- Insulation Resistance
- 100MOhm
- Pitch
- 0.020 0.50mm
- Total Number Of Contacts
- 28
- Uzunluk
- 16mm
- Montaj
- Surface Mount
- Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Mating Cycles
- 20
- Contact Resistance
- 100mOhm
- Ffc Fcb Thickness
- 0.30mm
- Plating Thickness
- FLASH inch
- Kurşunsuz
- Lead Free
- Ambalaj
- Tape & Reel (TR)
- RoHS Durumu
- RoHS Compliant
- Connector Type
- FFC/FPC CONNECTOR
- Actuatorcolor
- Black
- Voltage Rated Ac
- 50V
- Çalışma Sıcaklığı
- -55°C~85°C
- Terminal
- Solder
- Height Above Board
- 0.037 0.95mm
- Mil Conformance
- NO
- Locking Feature
- Flip Lock
- Montaj Tipi
- Surface Mount, Right Angle
- Filter Feature
- NO
- Ul Flammability Code
- 94V-0
- Pcb Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.037 inch
- JESD-609 Kodu
- e4
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Max Voltage Rating Ac
- 50V
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Beige
- Din Conformance
- NO
- Seri
- FH19SC
- Pozisyon Sayısı
- 28
- Flat Flex Type
- FFC, FPC
- Max Current Rating
- 500mA
- Current Rating Amps
- 0.5A
